ST 180 Meters OEM Customized Pneumatic Borewell Machine
ST 180 Meters OEM Customized Pneumatic Borewell Machine Information
ST 180 drilling rig is a type of light weight, high efficient, multiple functional drilling hole equipment. Which is equipped with advanced structure, easy to handle,high efficient, durable using etc , widely used for drilling well, farming irrigation well,geothermal air conditionhole and other usage well hole, especially suitable for water intaking in moutainnous area and rock layer
ST 180 Pneumatic Borewell Machine Techical Data
| Product Name | ST 180 drilling rig |
| Drilling hole diameter | 140-254mm |
| Drilling depth | 180m |
| One-time advance length | 3.3m |
| Walking speed | 2.5km/h |
| Climbing angles (Max.) | 30 |
| Equipped capacitor | 55kw |
| Using air pressure | 1.7-2.5mpa |
| Air consumption | 17-31m³/min |
| Drill pipe length | 1.5m, 2.0m, 3.0m |
| Drill pipe diameter | 76mm, 89mm |
| Rig lifting force | 12t |
| Swing speed | 45-65rpm |
| Swing torque | 3200-4600(N.m) |
| Dimension | 3800*1500*2200mm |
| Weight | 4500kg |
ST180 Pneumatic Borewell Machine Fetures
1. Guangxi Yuchai 55Kw turbocharged engine;
2. Walking device: walking motor reducer box, durable long life;
3. Hydraulic oil pump; parallel gearbox design (patent) oil pump monomer separation, power supply adequate distribution reasonable, hydraulic system unique design, simple maintenance, small cost;
4. Power head device, gearbox integrated casting, dual motor power, torque, durability, small maintenance costs;
5. Drill chassis; professional excavator chassis, durable, high bearing weight, chain plate width, small damage to the hard surface;
6. Lifting force; patent design composite big arm, big arm small volume, long stroke, double cylinder lifting, lifting tonnage;
7. Each drill hoist arm is installed limiter, protect the cylinder safety, ensure the safety of work;
8. Each hydraulic tubing is covered with a protective sleeve, so that the tubing life longer.
ST180 Pneumatic Borewell Machine FAQ
Q: Are you a manufacturer or trading company?
A: We are a professional drilling rig manufacturer.
Q: What are your main products, and used for?
A: Our products include core barrel, casing, drill rod, drill rig and other drilling parts.
They are used for mineral exploration, geological drilling.
Q: If the tool joint the buckle, the screw is not how to do?
A: You can tap and screw, this tool joint is not easy to take over tripping in use.
Q: How about the delivery terms?
A: 1.Payment: T/T,30% deposit advance and the rest before delivery
